1. The conveyor belt is connected by the belt buckle, and the joint can only reach about 70% of the rated tensile strength of the belt body, which is easy to cause fracture at the joint;

2．输送带接头直接通过输送带扣连接，输送带扣与带体垂直布置，受力更加集中，长时间在高强度拉力的工作条件下， 输送带扣与带面容易出现拔脱，造成断带；

2. The conveyor belt joint is directly connected through the conveyor belt buckle, and the conveyor belt buckle is vertically arranged with the belt body, so the force is more concentrated. Under the working condition of high tensile force for a long time, the conveyor belt buckle and the belt surface are easy to pull out, resulting in broken belt;

3．输送带扣与带体垂直布置，由于输送带中间的托辊承载70%的物料重量，两侧托辊各承载15%，这样输送带扣与各个滚筒托辊直线撞击擦过，导致输送带扣中间部分磨损严重；

3. The belt buckle is vertically arranged with the belt body. As the idler in the middle of the belt carries 70% of the material weight, and the idler on both sides carries 15% of the material weight respectively, the belt buckle and the idler of each drum collide and rub in a straight line, resulting in serious wear of the middle part of the belt buckle;

4．输送带主要采用的刮板式清扫器安装在卸载滚筒的下方，清扫器的刮板与输送带扣直线撞击过去，导致输送带扣和清扫器刮板磨损严重。

4. The scraper sweeper mainly used in the conveyor belt is installed under the unloading roller, and the scraper of the sweeper and the conveyor belt buckle collide in a straight line, resulting in serious wear of the conveyor belt buckle and the scraper of the sweeper.

织物输送带用带扣斜式连接结构，属于织物输送带连接扣技术领域， 是一种采用倾斜结构布置，能够有效增加输送带额定拉伸强度，减少受力集中，避免断带，降低输送带扣的磨损。织物输送带用带扣斜式连接结构，所采用的技术方案为织物输送带通过织物输送带扣连接，织物输送带扣之间贯穿有串条， 织物输送带的接头端为斜边，斜边与织物输送带带边的夹角为45°，沿织物输送带的接头端依次钉上斜式输送带扣，本技术广泛用于织物输送带的接头连接。

The oblique connection structure of belt buckle for fabric conveyor belt belongs to the technical field of fabric conveyor belt connection buckle. It is a kind of inclined structure arrangement, which can effectively increase the rated tensile strength of conveyor belt, reduce the stress concentration, avoid belt breakage and reduce the wear of conveyor belt buckle. The technical scheme adopted is that the fabric conveyor belt is connected through the fabric conveyor belt buckle, and a string of strips are penetrated between the fabric conveyor belt buckles, The joint end of the fabric conveyor belt is beveled edge, and the included angle between the beveled edge and the edge of the fabric conveyor belt is 45 degrees. The inclined conveyor belt buckle is nailed along the joint end of the fabric conveyor belt in turn. This technology is widely used in the joint connection of the fabric conveyor belt.

1．织物输送带用带扣斜式连接结构，包括织物输送带，织物输送带通过输送带扣连接，输送带扣之间贯穿有串条，织物输送带的接头端为斜边，斜边与织物输送带带边的夹角为45°，沿织物输送带的接头端依次钉上斜式输送带扣。

1. The fabric conveyor belt uses belt buckle inclined connection structure, including fabric conveyor belt. The fabric conveyor belt is connected by belt buckle, and there are string bars between belt buckles. The joint end of fabric conveyor belt is beveled edge, and the included angle between beveled edge and belt edge of fabric conveyor belt is 45 degrees. The beveled belt buckle is successively nailed along the joint end of fabric conveyor belt.
