裙边输送带可在环境温度-20℃+40℃范围内使用,被送物料温度小于60℃。
The skirt conveyor belt can be used in the range of ambient temperature - 20 ℃ to + 40 ℃, and the temperature of the delivered material is less than 60 ℃.
所以输送带在使用中应该注意以下事项:
Therefore, the conveyor belt in use should pay attention to the following matters:
(1) 避免托辊被物料覆盖,造成回转不灵,防止漏料卡于滚筒与胶带之间,注意活动部分的润滑,但不得油污输送带;
(1) Avoid the idlers being covered by materials, resulting in poor rotation, to prevent leakage stuck between the drum and the belt, pay attention to the lubrication of the moving part, but do not oil the conveyor belt;
(2)避免带负荷启动;
(2) Avoid starting with load;
(3)胶带发生跑偏,应该及时采取措施纠正;
(3) The belt deviation should be corrected in time;
(4)发现胶带局部操作应该及时修补,以免扩大;
(4) If it is found that the local operation of the adhesive tape should be repaired in time to avoid expansion;
(5)避免胶带遭受机架,支柱或块状物料的阻滞,防止碰破扯裂。
(5) Avoid the block of the belt by the frame, pillar or block material to prevent the belt from cracking.
1、 输送带在运输和贮存中,应保持清洁避免阳光直射或者雨雪浸淋,防止与酸碱油类有机溶剂等物质接触,并距离发热源少一米;
1. During transportation and storage, the conveyor belt should be kept clean, avoid direct sunlight or rain and snow, avoid contact with acid, alkali, oil, organic solvents and other substances, and be at least one meter away from the heat source;
2、 贮存时仓库内温度宜保持在-18℃-40℃之间,相对温度宜保持在50%-80%之间;
2. During storage, the temperature in the warehouse should be kept between - 18 ℃ and 40 ℃, and the relative temperature should be kept between 50% and 80%;
3、 贮存期间,产品须成卷放置,不得折叠,放置期间应每季翻动一次;
3. During storage, the products should be placed in rolls and not folded. During storage, they should be turned over once a quarter;
4、 不同类型、规格层数的输送带不宜接在一起,其接头较好采用胶接法;
4. The conveyor belts with different types, specifications and layers are not suitable to be connected together, and the bonding method is better;
5、 输送带的类型、结构、规格、层数应根据使用条件合理选用。
5. The type, structure, specification and number of layers of conveyor belt should be selected reasonably according to the service conditions.
6、 输送胶带运行速度一般不宜大于2.5米/秒,块度大,磨损性大的物料和使用固定类型卸料装置应尽量采用低速;
6. Generally, the running speed of conveyor belt should not be greater than 2.5 m / s. low speed should be used for materials with large block size and wear resistance and fixed discharge device;
7、 运输机的传动滚筒直径与输送带布层的关系,传动滚筒,改向滚筒的配套以及对托辊槽角的要求应根据运输机的设计规定,合理选取;
7. The relationship between the diameter of the driving roller and the cloth layer of the conveyor belt, the matching of the driving roller and the steering roller, and the requirements for the groove angle of the idler should be reasonably selected according to the design regulations of the conveyor;
8、 给料方向应顺胶带的运行方向,为减小物料下落时对胶带的冲击应采用溜槽,减少物料下落距离;胶带受料段应缩短托辊间距和采用缓冲托辊,为防止漏料,带侧应采用柔软适度的挡料板,以免挡料板过硬,刮破输送带的带面。
8. The feeding direction should be along the running direction of the belt. In order to reduce the impact of falling materials on the belt, chute should be used to reduce the falling distance of materials; The distance between rollers should be shortened and buffer rollers should be used in the receiving section of the belt. In order to prevent material leakage, a soft and moderate baffle plate should be used at the belt side, so as not to scratch the belt surface of the conveyor belt.
