1. 当拆卸爬坡传送带时。用副斜井运输卷扬机的绳系好爬坡输送带向外拉，带式输送机点动开始。输送带完成后，应切断电源，启动下一步。在井口室做好皮带的工作，皮带与皮带头有信号接触，从手动开始卷绕皮带，大约200米，停止滚动皮带，撕掉皮带，用铅(外观：用蓝银)丝带扎紧扎。
1. When removing the climbing belt. Use the rope of the auxiliary inclined shaft hoist to fasten the climbing belt, pull it outward, and the belt conveyor starts to jog. After the conveyor belt is finished, cut off the power and start the next step. First of all, do a good job in the wellhead room. There is a signal contact between the belt and the belt head. Start winding the belt manually, about 200 meters, stop rolling the belt, tear off the belt, and fasten it with lead (appearance: blue silver) ribbon.
2. 拆下托辊(支撑传送带、物料重量和中间机架)，拆下中间机架(G、N)上的三个滚筒和直辊，然后手动将其运地面。四个人拿着中间的框架一个人用扳手拧松硬框架的螺丝，四个人慢慢放下中间的框架。根据实际情况调整中间架，人工抬离地面。使用相同的方法回收中间框架的其余部分。
2. Remove the idler (supporting conveyor belt, material weight and intermediate frame), remove the three rollers and straight rollers on the intermediate frame (g, n), and then transport them to the ground manually. Four people hold the middle frame, one uses a wrench to loosen the screws of the hard frame, and four people slowly put down the middle frame. Adjust the intermediate frame according to the actual situation and lift it off the ground manually. Use the same method to recycle the rest of the intermediate framework.
3.机器的尾部和转运头应由尾部和转运头的车行道顶部的两根锚索支撑。将落煤槽穿过锚绳，用索具将爬坡的输送带固定，并与马蹄环连接，马蹄环与钢丝连接紧密，悬挂5吨链条。用钢丝绳(由钢丝、绳芯和油脂组成)三个绳夹将待组装的设备绑牢，挂在链钩上。拉动小链条，使设备难以装配。然后手动松开搁板与基础之间的连接装置。，从架子上卸下螺丝，松开链条，慢慢地把设备放在地上或放在收割机上运走。
3. The tail and transfer head of the machine shall be supported by two anchor cables at the top of the carriageway of the tail and transfer head. Pass the coal chute through the anchor rope, fix the climbing conveyor belt with the sling, and connect it with the horseshoe ring, which is closely connected with the steel wire, and hang 5 tons of chain. Bind the equipment to be assembled with three clamps of steel wire rope (composed of steel wire, rope core and grease) and hang it on the chain hook. Pull the small chain to make the equipment difficult to assemble. Then manually release the connection between the shelf and the foundation. Finally, remove the screw from the rack, loosen the chain, and slowly put the equipment on the ground or on the harvester to transport away.
