The structure of the conveyor belt is mainly composed of tensile layer (skeleton) and covering layer (protective layer), and the skeleton is divided into fabric and metal.

因抗拉层（骨架）在工作中承担全部的负荷，所以要具备的强度和刚度。

Due to the tensile layer (skeleton) in the work to bear all the load, so the strength and stiffness to have.

覆盖层（保护层）的作用就是保护抗拉层（骨架）免于受到直接的冲击、磨损、腐蚀等因素以防止抗拉层（骨架）的早期损坏。

The function of the covering layer (protective layer) is to protect the tensile layer (skeleton) from direct impact, wear, corrosion and other factors, so as to prevent the early damage of the tensile layer (skeleton).

（一）织物芯输送带的结构

（1） Structure of fabric core conveyor belt

织物包括棉帆布（CC）、锦纶帆布（NN—尼龙帆布）、涤锦帆布（EP—聚酯帆布），织物芯输送带又分为叠层（多层）带芯和整体（单层）带芯两种。

Fabric includes cotton canvas (CC), nylon canvas (NN nylon canvas) and polyester nylon canvas (EP polyester canvas). Fabric core conveyor belt is divided into two types: laminated (multi-layer) belt core and integral (single layer) belt core.

叠层织物芯输送带的结构

Structure of laminated fabric core conveyor belt

叠层织物芯输送带主要由：多层帆布组成的带芯、上、下覆盖层和边胶组成的，在贴合时要求各层帆布的张力达到一致。

The laminated fabric core conveyor belt is mainly composed of the belt core composed of multi-layer canvas, upper and lower covering layers and edge glue, and the tension of each layer of canvas is required to be consistent during lamination.

包头输送带

Baotou conveyor belt

整体织物芯输送带的结构

Structure of integral fabric core conveyor belt

整体织物芯输送带是由单层织物和上下覆盖层组成，具有较高的阻燃性，主要适用于煤矿井下输送煤炭的场所。

The integral fabric core conveyor belt is composed of single-layer fabric and upper and lower covering layers, which has high flame retardancy and is mainly suitable for coal transportation in underground coal mines.

（二）金属芯输送带的结构

（2） Structure of metal core conveyor belt

钢丝绳芯输送带的结构

Structure of steel cord conveyor belt

适用于较长距离输送物流的场所，具有强度高寿命长的特点。

It is suitable for long distance transportation of logistics, with the characteristics of high strength and long life.

钢网芯输送带的结构

Structure of steel mesh core conveyor belt

主要应用于钢铁行业的高温环境（耐灼烧）。

It is mainly used in high temperature environment of iron and steel industry.
