1、尼龙输送带在运输和贮存中,应保持清洁避免阳光直射或雨雪浸淋,防止与酸、碱、油类、有 机溶剂等物质接触,并距离发热装置一米以外尼龙输送带。
1. During transportation and storage, the nylon conveyor belt shall be kept clean, avoid direct sunlight or rain and snow, prevent contact with acids, alkalis, oils, organic solvents and other substances, and the nylon conveyor belt shall be one meter away from the heating device.
2、贮存时仓库温度宜保持一18-40℃之间,相对湿度宜保持在 50-80%之间。
2. During storage, the warehouse temperature should be kept between 18-40 ℃ and the relative humidity should be kept between 50-80%.
3 、贮存期间,产品须成卷放置,不得折迭,放置期间应每季翻动一次。
3. During storage, the products shall be placed in rolls without folding, and shall be turned once a quarter during storage.
4 、不同类型、规格层数的输送带不宜接在一起使用,其接头更好采用胶接法。
4. Conveyor belts of different types, specifications and layers should not be used together, and their joints should preferably be bonded.
5 、尼龙输送带的类型、结构、规格、层数应根据使用条件合理选用。
5. The type, structure, specification and number of layers of nylon conveyor belt shall be reasonably selected according to the service conditions.
尼龙输送带的保养和使用说明是怎么样的
What are the maintenance and operation instructions for nylon conveyor belt
6 、尼龙输送带运行速度一般不宜大于2.5米/秒,块度大,磨损性大的物料和使用固定梨的 卸料装置应尽量采用低速。
6. Generally, the running speed of nylon conveyor belt should not be greater than 2.5m/s. Low speed should be used as far as possible for materials with large lumpiness and high wear and unloading devices using fixed pears.
7 、运输机的传动滚筒直径与输送带布层的关系、传动滚筒、改向滚筒的配套以及对 托辊槽角 的要求应根据运输机的设计规定,合理选取。
7. The relationship between the diameter of the transmission drum of the conveyor and the cloth layer of the conveyor belt, the matching of the transmission drum and the redirection drum and the requirements for the groove angle of the idler shall be reasonably selected according to the design regulations of the conveyor.
8 、给料方向应顺胶带的运行方向,为减小物料下落时对胶带的冲击应采溜槽,减小物料下落距离;胶带受料段应缩短托辊间距和采用缓冲吊装托辊为漏料,带顺应采用柔软适度的挡料板,以免档料板过硬,刮破输送带的带面。
8. The feeding direction should follow the running direction of the belt. In order to reduce the impact on the belt when the material falls, a chute should be used to reduce the falling distance of the material; In the material receiving section of the belt, the distance between the idlers shall be shortened and the buffer lifting idlers shall be used for material leakage. The belt shall comply with the requirements and adopt a soft and appropriate baffle plate to prevent the baffle plate from being too hard and scratching the belt surface of the conveyor belt.
9 、食品级输送带在使用中应注意以下事项:
9. Food grade conveyor belt shall pay attention to the following matters in use:
①避免托辊被物料覆盖,造成回转不灵,防止漏料卡于滚筒与胶带之间,注意活动部分的润滑,但不得油污输送胶带;②避免机械加工带负荷启动;③胶带发生跑偏,应用时采取措施纠正;④发现胶带局部损人造棉应用时修补,以免扩大尼龙输送带。
① Prevent the idler from being covered by materials, resulting in poor rotation, prevent material leakage from being stuck between the drum and the belt, pay attention to the lubrication of the moving part, but do not transport the belt with oil stain; ② Avoid mechanical processing with load start-up; ③ If the tape deviates, take measures to correct it during application; ④ If it is found that the tape is damaged locally by man-made cotton, it shall be repaired during application to avoid expanding the nylon conveyor belt.
