1. Put on the flexible shaft on the coiling core of the conveyor belt, and frame the belt. Pay attention to the direction of the upper and lower cover rubber before putting on the frame. The conveyor belt is divided into ordinary conveyor belt and strong conveyor belt according to the tensile strength of the conveyor belt cloth layer. The strong canvas conveyor belt is divided into nylon conveyor belt (NN conveyor belt) and polyester conveyor belt (EP conveyor belt). Heat resistant conveyor belt is composed of multi-layer rubber cotton canvas (polyester cotton cloth) or polyester canvas, which is covered with high temperature resistant or heat-resistant rubber and bonded together by high temperature vulcanization. It is suitable for conveying hot coke, cement, slag and hot casting under 175 ℃.

2、在不宜上架的工作场所可以把输送带卷导开，并使折叠（含义:把物体的一部分折过)处输送带具有足够大曲率半径，防止损伤输送带，折叠（含义:把物体的一部分折过)处禁止在输送带上放置重物。

2. In the workplace where it is not suitable to put on the rack, the conveyor belt can be rolled and guided, and the conveyor belt at the folding (meaning: folding part of the object) has enough curvature radius to prevent damage to the conveyor belt. It is forbidden to place heavy objects on the conveyor belt at the folding (meaning: folding part of the object).

3、如果是更换输送带，可将新带与旧带连在共同，卸带与安装新输送带同时进行。

3. If the belt is replaced, the new belt can be connected with the old belt, and the unloading and installation of the new belt can be carried out at the same time.

4、对于水平运转的输送机，可在任何一点切断（割开；截断)旧输送机，倾斜方向运转的输送机，则需选好切断点，防止因自重引起下滑而失控。

4. For the conveyor running horizontally, the old conveyor can be cut off (cut; cut) at any point. For the conveyor running in the inclined direction, the cut-off point shall be selected to prevent the conveyor from falling out of control due to its own weight.

5、在输送机上将新带的位置放正后，用夹具将胶带的一端固定好，然后与绕过辊与带轮的绳索相连，通过牵引装置将输送带平衡地架到输送机上，牵引时，要防止输送带与机架相互挤压。

5. After the new belt is placed in the right position on the conveyor, one end of the belt is fixed with a clamp, and then connected with the rope bypassing the roller and the pulley. The conveyor belt is balanced on the conveyor through the traction device. During traction, the conveyor belt and the frame shall be prevented from squeezing each other.

6、用夹具将输送带的一端固定在输送机架上，另一端通过滑轮将另一端拉紧，直到输送带在返回托辊(支撑输送带和物料重量)上无明显下垂。

6. One end of the conveyor belt is fixed on the conveyor frame with a clamp, and the other end is tightened by a pulley until there is no obvious sag of the conveyor belt on the return idler (supporting the conveyor belt and material weight).

7、将张紧装置固定离起点100~150mm。

7. Fix the tensioning device 100-150 mm away from the starting point.

如果您想了解更多的关于输送带方面的技术问题或疑惑，请致公司 1、在输送带卷取铁芯上穿上转动灵活的轴，并将带卷架好，上架前注意(attention)上、下盖胶的方向不要架反。输送带按照 输送带布层拉力强度分为普通输送带、强力输送带。强力型的帆布 输送带分为尼龙 输送带（NN输送带）和聚酯 输送带（EP 输送带）。耐热输送带是由多层橡胶棉帆布（涤棉布）或者聚酯帆布上下覆有耐高温或耐热橡胶、经高温硫化粘合在一起，适合输送175℃以下热焦碳、水泥、熔渣和热铸件等。

If you want to know more about the technical problems or doubts about the conveyor belt, please send to the company 1. Put on the flexible rotating shaft on the coiling core of the conveyor belt, and roll the belt well. Pay attention to the direction of the upper and lower cover rubber before putting it on the rack. The conveyor belt is divided into ordinary conveyor belt and strong conveyor belt according to the tensile strength of the conveyor belt cloth layer. The strong canvas conveyor belt is divided into nylon conveyor belt (NN conveyor belt) and polyester conveyor belt (EP conveyor belt). Heat resistant conveyor belt is composed of multi-layer rubber cotton canvas (polyester cotton cloth) or polyester canvas, which is covered with high temperature resistant or heat-resistant rubber and bonded together by high temperature vulcanization. It is suitable for conveying hot coke, cement, slag and hot casting under 175 ℃.

2、在不宜上架的工作场所可以把输送带卷导开，并使折叠（含义:把物体的一部分折过)处输送带具有足够大曲率半径，防止损伤输送带，折叠（含义:把物体的一部分折过)处禁止在输送带上放置重物。

2. In the workplace where it is not suitable to put on the rack, the conveyor belt can be rolled and guided, and the conveyor belt at the folding (meaning: folding part of the object) has enough curvature radius to prevent damage to the conveyor belt. It is forbidden to place heavy objects on the conveyor belt at the folding (meaning: folding part of the object).

3、如果是更换输送带，可将新带与旧带连在共同，卸带与安装新输送带同时进行。

3. If the belt is replaced, the new belt can be connected with the old belt, and the unloading and installation of the new belt can be carried out at the same time.

4、对于水平运转的输送机，可在任何一点切断（割开；截断)旧输送机，倾斜方向运转的输送机，则需选好切断点，防止因自重引起下滑而失控。

4. For the conveyor running horizontally, the old conveyor can be cut off (cut; cut) at any point. For the conveyor running in the inclined direction, the cut-off point shall be selected to prevent the conveyor from falling out of control due to its own weight.

5、在输送机上将新带的位置放正后，用夹具将胶带的一端固定(fixed)好，然后与绕过辊与带轮的绳索相连，通过牵引装置将输送带平衡地架到输送机上，牵引时，要防止输送带与机架相互挤压。

5. After the new belt is placed in the right position on the conveyor, fix one end of the belt with a clamp, and then connect it with the rope bypassing the roller and the belt wheel. The conveyor belt is balanced on the conveyor through the traction device. When traction, the conveyor belt and the frame shall be prevented from squeezing each other.

6、用夹具将输送带的一端固定在输送机架上，另一端通过(滑轮将另一端拉紧，直到输送带在返回托辊(支撑输送带和物料重量)上无明显下垂。

6. One end of the conveyor belt is fixed on the conveyor frame with a clamp, and the other end is tightened by a pulley until there is no obvious sag of the conveyor belt on the return idler (supporting the conveyor belt and material weight).

7、将张紧装置固定(fixed)离起点100~150mm。

7. Fix the tensioning device 100-150 mm away from the starting point.
