食品输送带在运输和贮存种,应保持清洁避免阳光直射或雨、雪浸淋,防止与酸、碱油类、有机溶剂等物质接触,并距离发热装置一米以外。
During transportation and storage, the food conveyor belt shall be kept clean, avoid direct sunlight or rain and snow, prevent contact with acids, alkali oils, organic solvents and other substances, and be one meter away from the heating device.
贮存时仓库内温度宜保持 -18℃ - 40℃ 之间,相对温度宜保持在50-80%RH之间。贮存期间,产品需成卷放置,不得折叠,放置期间应每季翻动一次。不同类型、规格层数的输送带不宜接在一起使用,其接头更好采用胶接法。
During storage, the temperature in the warehouse should be kept between - 18 ℃ - 40 ℃, and the relative temperature should be kept between 50-80% RH. During storage, the product shall be placed in rolls and shall not be folded. During storage, it shall be turned once a quarter. Conveyor belts of different types, specifications and layers should not be connected together, and their joints should preferably be bonded.
输送带的类型、结构、规格、层数应根据使用条件合理选用。输送带运行速度一般不宜大与2.5米/秒,块度大,磨损性大的物料和使用固定犁型卸料装置应尽量采用低速。输送机的传动滚筒直径与输送带布层的关第、传诵滚筒、改向滚筒的配套以及对托辊槽角的要求应根据运输机的设计规定,合理选取。
The type, structure, specification and number of layers of conveyor belt shall be reasonably selected according to the service conditions. Generally, the running speed of the conveyor belt should not be higher than 2.5m/s. Low speed should be used as far as possible for materials with large block and high wear and the use of fixed plow unloading device. The diameter of the transmission drum of the conveyor and the relationship between the cloth layer of the conveyor belt, the matching of the recitation drum and the redirection drum, and the requirements for the idler groove angle shall be reasonably selected according to the design regulations of the conveyor.
给料方向应顺胶带的运行方向,为减少物料下落时对胶带的冲击应采用溜槽,减少物料下落距离;胶带受料段应缩短托辊间距和采用缓冲托辊,为防止漏料,带侧应采用柔软适度的挡料板,以避免挡料板过硬,刮破输送带的带面。
The feeding direction shall be along the running direction of the belt. In order to reduce the impact on the belt when the material falls, a chute shall be used to reduce the falling distance of the material; The distance between idlers shall be shortened and buffer idlers shall be used in the material receiving section of the belt. In order to prevent material leakage, a soft and appropriate baffle plate shall be used on the belt side to prevent the baffle plate from being too hard and scratching the belt surface of the conveyor belt.
使用注意事项:
Precautions for use:
(1) 避免托辊被物料覆盖,造成回转不灵,防止漏料卡于滚筒与胶带之间,注意活动部分的润滑,但不得油污输送带;
(1) Prevent the idler from being covered by materials, resulting in poor rotation, prevent material leakage from being stuck between the drum and the belt, and pay attention to the lubrication of the moving part, but do not oil the conveyor belt;
(2)避免带负荷启动;
(2) Avoid starting with load;
(3)胶带发生跑偏,应该及时采取措施纠正;
(3) If the tape deviates, measures shall be taken to correct it in time;
(4)发现胶带局部操作应该及时修补,以免扩大;
(4) In case of local operation of the tape, it shall be repaired in time to avoid expansion;
(5)避免胶带遭受机架,支柱或块状物料的阻滞,防止碰破扯裂。
(5) Prevent the tape from being blocked by frame, pillar or block materials to prevent it from breaking and tearing.
