(1)工作时无滑动，有准确的传动
(1) There is no sliding during operation, and there is accurate transmission
(2)传动效率高，效果好
(2) High transmission efficiency and good energy-saving effect
(3)传动比范围大，结构紧凑
(3) Large transmission ratio range and compact structure
(4)维护保养方便，运转费用低
(4) Convenient maintenance and low operation cost
(5)恶劣环境条件下仍能正常工作
(5) It can still work normally under harsh environmental conditions
同步轮的选型步骤
Selection steps of synchronous wheel
同步带传动机构一般按以下步骤进行计算与选型
The synchronous belt transmission mechanism is generally calculated and selected according to the following steps
(1)设计条件
(1) Design conditions
同步带传动设计,通常都是在以下已知条件下进行的
The design of synchronous belt transmission is usually carried out under the following known conditions
①同步带需要传递的功率
① Power to be transmitted by synchronous belt
②主动轮转速、从动轮转速或传动比
② Driving wheel speed, driven wheel speed or transmission ratio

③同步带轮安装距离;
③ Installation center distance of synchronous pulley;
④工作条件等
④ Working conditions, etc
需要计算选型确定的项目包括
Items to be calculated and selected include
同步带节距、宽度、节线长度、实际距、同步带轮齿数等,并将各参数用符号表示再向制造商订购同步带、同步带轮。
Timing belt pitch, width, pitch length, actual center distance, number of teeth of timing belt, etc. all parameters are represented by symbols, and then order timing belt and timing belt pulley from the manufacturer.
（2）根据转速、功率选定同步带带型
(2) The timing belt type is selected according to the speed and power
同步带带型选型就是根据同步带所需要传递的负载功率及主动轮转速选择合适的同步带齿型及节距
The selection of synchronous belt type is to select the appropriate synchronous belt tooth type and pitch according to the load power and driving wheel speed that the synchronous belt needs to transmit
同步带不同节距齿型的同步带其单位宽度所能够传递的功率是不同的，同一规格的同步带在不同的转速下所能够传递的功率也不同。为了方便用户正确地选用同步带,制造商对不同类型、不同节距的同步带在不同转速下能够传递的功率制成图表，用户可以根据图表接选用合适的同步带类型和节距。
Synchronous belts with different pitch tooth types can transmit different power per unit width, and synchronous belts of the same specification can transmit different power at different speeds. In order to facilitate users to correctly select synchronous belts, the manufacturer makes charts for the power that can be transmitted by synchronous belts of different types and pitches at different speeds. Users can select appropriate synchronous belt types and pitches according to the charts.
