Now, many people may discard or replace the conveyor belt in Shandong because of a little damage, which greatly increases the cost consumption of the conveyor belt. In fact, sometimes we can reuse it through appropriate repair, but we should emphasize that if the damage is too large, it should be replaced in time, so we should pay attention to this point, The following small series will introduce to you how to repair if the conveyor belt is partially damaged.

由于使用条件恶劣，输送带很可能受到一些损伤，为不使损伤扩大，以限度地满足使用，应对输送带的有些损伤进行修补。

Due to poor service conditions, the conveyor belt is likely to suffer some damage. In order not to expand the damage and meet the use to the greatest extent, some damage of the conveyor belt should be repaired.

帆布层芯输送带的修补

Repair of canvas core conveyor belt

修补方式根据损坏的状况，按下表选择相应的修补方式：

Repair method according to the damage condition, select the corresponding repair method according to the following table:

损坏状况损坏程度修补方式盖胶损伤损伤仅在盖胶，没伤及带坯不需修补盖胶有损伤并伤及带坯冷压 硫化修补带坯损伤带坯损伤点小于带层数量的1/2

Damage condition damage degree repair method the damage of the cover rubber is only in the cover rubber, and there is no need to repair the belt blank. The cover rubber is damaged and the belt blank is damaged by cold pressing vulcanization. The damage point of the belt blank is less than 1 / 2 of the number of belt layers

冷压硫化修补带坯损伤点大于带层数量的1/2

The damage point of cold press vulcanization repair belt blank is greater than 1 / 2 of the number of belt layers

硫化板修补带坯损伤范围超过1/3带宽切除损伤部分，

The damage range of vulcanized plate repair strip blank exceeds 1 / 3 of the bandwidth, and the damaged part is removed,

重新接料接头损伤仅损及盖胶冷压硫化修补损及带坯切除损伤部分，

The damage of rejoining joint only damages the damaged part of cover rubber cold press vulcanization repair and belt blank removal,

重新接料纵向裂缝裂缝较短硫化板修补裂缝较长加新带重新接头修补材料

The longitudinal crack of reconnection material is shorter, the repair crack of vulcanized plate is longer, and a new belt reconnection repair material is added

（1）硫化板修补：盖胶、胶粘剂、帆布加强层（与主带相同的帆布）。

(1) Vulcanized plate repair: cover glue, adhesive and canvas reinforcing layer (the same canvas as the main belt).

（2）冷压硫化修补：盖胶、填充胶、缓冲胶、胶粘剂。

(2) Cold press vulcanization repair: cover glue, filling glue, buffer glue and adhesive.

（3）盖胶损伤的修补

(3) Repair of cover glue damage
