Shandong layered fabric conveyor belt is divided into three types

1、棉帆布输送带：

1. Cotton canvas conveyor belt:

适用于短距离和中等负载条件下的物料输送，张力相对较低，承重有限

It is suitable for material transportation under short distance and medium load conditions. The tension is relatively low and the load is limited

2、尼龙输送带：\ n 尼龙输送带具有带薄、耐冲击、凹槽成型性好、柔韧性好、使用寿命长等特点。适用于中长距离、高负荷、高速条件下的物料输送。

2. Nylon conveyor belt has the characteristics of long impact resistance and good service life. It is suitable for material transportation under medium and long distance, high load and high speed conditions.

3、涤纶输送带：

3. Polyester conveyor belt:

带体模量高、伸长率小、热稳定性好、耐冲击、强度高、柔韧性好、使用寿命长，适用于中长距离、高自由度、高速输送物料。

The belt has high modulus, small elongation, good thermal stability, impact resistance, high strength, good flexibility and long service life. It is suitable for medium and long distance, high degree of freedom and high-speed transportation of materials.

山东聚酯输送带

Shandong polyester conveyor belt

涤纶输送带是由多层涤纶（或径向涤纶，纬向涤胺）帆布按一定方式粘合而成，上下罩覆有强度高、弹性好的磨胶。适用于中长距离、高载重、高速运输。

Polyester conveyor belt is made of multi-layer polyester (or radial polyester, weft polyester amine) canvas bonded in a certain way, and the upper and lower covers are covered with grinding glue with high strength and good elasticity. It is suitable for medium and long distance, high load and high-speed transportation.

种类：Type:

普通型、耐油型、耐酸碱型、耐热型、耐高温型、耐燃烧型、阻燃型、耐寒型、耐磨型。

Ordinary type, oil resistant type, acid and alkali resistant type, heat resistant type, high temperature resistant type, combustion resistant type, flame retardant type, cold resistant type and wear resistant type.

规格型号：Specification and model:

面料型号：EP100、EP150、EP200、EP250、EP300、EP350、EP400

Fabric model: EP100, EP150, ep200, ep250, ep300, ep350, ep400

单层织物强度：100、150、200、250、300、350、400(N/mm)

Single layer fabric strength: 100, 150, 200, 250, 300, 350, 400 (n / mm)

带宽：300-3200mm

Bandwidth: 300-3200mm

层数：2-8层Number of floors: 2-8

涂胶：1.5+1.5、3.0+1.5、4.0+2.0、4.5+1.5、4.5+3.0、6.0+1.5、6.0+3.0

Gluing: 1.5 + 1.5, 3.0 + 1.5, 4.0 + 2.0, 4.5 + 1.5, 4.5 + 3.0, 6.0 + 1.5, 6.0 + 3.0

特征 ：features:

1、带体模量高，伸长率小。

1. The belt has high modulus and low elongation.

2、良好的热稳定性、抗冲击性和高强度。

2. Good thermal stability, impact resistance and high strength.

3. 优良的柔韧性和长使用寿命。

3. Excellent flexibility and long service life.

所以建议使用涤纶输送带！！！

Therefore, it is recommended to use polyester conveyor belt!!!

聚酯输送带又称EP输送带、耐磨输送带、自动输送带、水泥输送带，具有体模量高、伸长率低、耐热稳定性好、耐冲击，适用于中长距离和相对高剪裁，在高速条件下输送物料。

Polyester conveyor belt, also known as EP conveyor belt, wear-resistant conveyor belt, automatic conveyor belt and cement conveyor belt, has high bulk modulus, low elongation, good heat stability and impact resistance. It is suitable for medium and long distance and relatively high cutting and conveying materials at high speed.

山东聚酯输送带（EP输送带）用于煤炭、矿山、港口、冶金、电力、化工等领域输送物料。

Shandong polyester conveyor belt (EP conveyor belt) is used to transport materials in coal, mining, port, metallurgy, electric power, chemical industry and other fields.

涤纶输送带分类

Classification of polyester conveyor belt

①按包覆胶的性能分为耐寒耐酸、耐碱、耐油、耐磨等。

① According to the properties of coating adhesive, it can be divided into cold resistance, acid resistance, alkali resistance, oil resistance, wear resistance, etc.

②聚酯输送带按使用环境不同分为橡胶输送带，包括（普通型、耐热型、阻燃型、耐燃型、耐酸碱型、耐油型）、耐热型输送带、耐寒输送带、耐酸碱输送带、耐油输送带、食品输送带等型号。其中，普通输送带和食品输送带上的低盖胶厚度为3.0mm，下盖胶为1.5mm；耐热输送带、耐寒输送带、耐酸碱输送带、耐油输送带低覆盖胶厚度为4.5mm，下覆盖胶厚度为2.0mm。

② Polyester conveyor belts can be divided into rubber conveyor belts according to the use environment, including (ordinary type, heat resistant type, flame retardant type, flame resistant type, acid and alkali resistant type, oil resistant type), heat resistant conveyor belt, cold resistant conveyor belt, acid and alkali resistant conveyor belt, oil resistant conveyor belt, food conveyor belt and other models. Among them, the thickness of low cover glue on ordinary conveyor belt and food conveyor belt is 3.0mm, and the thickness of lower cover glue is 1.5mm; The thickness of low covering glue of heat-resistant conveyor belt, cold resistant conveyor belt, acid and alkali resistant conveyor belt and oil resistant conveyor belt is 4.5mm, and the thickness of lower covering glue is 2.0mm.

③根据使用环境的具体情况，上下覆盖胶的厚度可增加1.5mm。

③ The thickness of the upper and lower covering glue can be increased by 1.5mm according to the specific conditions of the service environment.
