Introduction: whole core flame retardant conveyor belt is mainly used in coal mine.

特点：带体不脱层，伸长小，抗冲击，耐撕裂。

Features: no delamination, small elongation, impact resistance and tear resistance.

按结不同可以分为

According to the different knot can be divided into

PVC型（塑料面），

PVC type (plastic surface),

PVG型（在PVC基础上加附橡胶面）整芯阻燃带，执行MT/914-2002标准。

PVG type (with rubber surface on the basis of PVC) whole core flame retardant tape, in accordance with MT / 914-2002 standard.

PVC型适用于16度以下倾角的干燥条件下的物料输送。

PVC type is suitable for material transportation under dry condition with inclination angle below 16 degrees.

PVG型适用于20度以下倾角的潮湿有水物料的输送。

PVG type is suitable for conveying wet and watery materials with inclination angle below 20 degrees.

1、型号N/mm（拉伸强度）：

1. Model n / mm (tensile strength)

级别：4级  5级   6级   7级   8级   9级  10级

Level: Level 4, level 5, level 6, level 7, level 8, level 9, level 10

型号：680s 800s 1000s 1250s 1400s 1600s 1800s

Model: 680s 800s 1000s 1250s 1400s 1600s 1800s

2、阻燃性能：（1）滚筒磨数：滚筒表面温度不大于325℃。

2. Flame retardant properties: (1) roller grinding number: roller surface temperature is not more than 325 ℃.

（2）喷灯燃烧：全厚试件去喷灯无火焰时间平均不大于3.0S，去覆盖层平均不大于5.0S。（3）丙烷燃烧：无损长度大于250mm3、表面电阻值：上、下面平均值不大于3.0×108Ω

本文由切菜机输送带进行编写，想要了解更多的产品及更详细的精彩内容，请关注我们的网站：https://www.huafengxiangsu.com

(2) Burner burning: the average flameless time of full thickness specimen to burner is not more than 3.0s, and the average time to cover is not more than 5.0s（ 3) Propane combustion: Nondestructive length greater than 250mm3, surface resistance value: upper and lower average value less than 3.0 × one hundred and eight Ω
