1、自动拖辊调偏：当保送带跑偏范围不大时，可在保送带跑偏处，装置调心拖辊。
1. Auto-roll deflection adjustment: When the range of deviation of the belt is not large, the center-adjusting roll can be installed at the deviation of the belt.
2、恰当拉紧调偏：当保送带跑偏忽左忽右，方向不定时阐明保送带过松，可恰当调整拉紧安装以消弭跑偏。
2. Proper tightening and deflection adjustment: When the delivery belt runs left and right, and the direction is uncertain, it is explained that the delivery belt is too loose, and the tightening installation can be adjusted appropriately to avoid running off.
3、单侧立辊调偏：保送带一直向一侧跑偏，可在范围内加装若干立辊，使胶带复位。
3. One-side vertical roll deflection adjustment: the belts run to one side all the time. Several vertical rollers can be installed in the range to make the belts reset.
4、调整滚筒调偏：保送带在滚筒处跑偏，检查滚筒能否异常或窜动，调整滚筒程度位置正常转动，消弭跑偏。
4. Adjust the deviation of the drum: the delivery belt runs away at the drum, check whether the drum can move abnormally or not, adjust the drum to the normal rotation of the degree position, eliminate the deviation.
5、校正保送带接头调偏；保送带跑偏一直一个方向，且大跑偏在接头处，可校正保送带接头与保送带中线垂直消弭跑偏
5. Correct the deviation of the joint of the delivery belt; the deviation of the delivery belt is always in one direction, and the maximum deviation is at the joint, which can correct the vertical deviation between the joint of the delivery belt and the midline of the delivery belt.
6、垫高拖辊调偏：保送带跑偏方向、间隔一定，可在跑偏方向的对侧垫高拖辊若干组，消弭跑偏。
6. Adjusting the deviation of the tow rollers with high cushion: if the direction and interval of the belt are fixed, several groups of tow rollers can be cushioned on the opposite side of the deviation direction to eliminate the deviation of the tow rollers.
7、调整拖辊调偏：保送带跑偏方向一定，检查发现拖辊中线与保送带中线不垂直，就可调整拖辊，消弭跑偏。
7. Adjust the deviation of the tow roll: The direction of the running deviation of the tow belt is certain. If it is found that the middle line of the tow roll is not perpendicular to the middle line of the tow belt, the tow roll can be adjusted to eliminate the deviation of the tow roll.
8、消弭隶属物调：保送带跑偏点不变，发现拖辊、滚筒粘有隶属物，就要肃清后消弭跑偏。
8. Eliminate subordinate adjustments: the deviation point of the escort belt remains unchanged. If it is found that there are subordinate objects in the tow rollers and drums, it is necessary to eliminate the deviation after cleaning up.
9、校正给料跑偏：胶带轻载不偏，重载跑偏，可调整给料重量及位置消弭跑偏。
9. Correction of feeding deviation: the tape is not deviated under light load and heavy load. The weight and position of feeding can be adjusted to eliminate the deviation.
10、校正支架调偏：保送带跑偏方向、位置固定、跑偏严重可调整支架的程度和垂直度，消弭跑偏。
10. Adjusting the deflection of the support: the direction, position and serious deflection of the escort belt can adjust the degree and verticality of the support to eliminate the deflection.
